MIL-DTL-62462 Engine, Diesel, Liquid-Cooled, 8 Cylinder; 4 Cycle, V-Type, 220 Kw \(295 Hp\)This specification covers the requirements for a liquid cooled, 4 cycle, 90 degree V-type, 8 cylinder internal combustion, compression ignition engine. At 2600 revolutions per minute \(rpm\), the diesel engine is rated at 220 kilowatts \(kW\) \(295 horsepower \(hp\)\). The diesel engine, and the associated accessories furnished by the engine supplier are referred to herein as "engine".

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20

MIL-DTL-62462D(AT)

949

MAXIMUM

(700)

881

(650)

814

(600)

746

CONTINUOUS

(550)

678

(500)

MAXIMUM

224

(300)

205

(275)

186

(250)

CONTINUOUS

168

(225)

149

(200)

130

(175)

112

(150)

MAXIMUM

.243

(.400)

.213

(.350)

140

160

180

200

220

240

260

ENGINE SPEED, rpm

NOTES:

1. All data is based on the engine operating with fuel system, water pump, lubricating oil

pump, air cleaner, and muffler; not included are alternator, compressor, fan, optional

equipment and driven components.

2. Curves shown above represent engine performance capabilities at SAE J1349 conditions of

150 meter (m) (500 feet (ft)) altitude [98.21 kilopascals (kPa) (29 inches mercury (in. Hg))

dry barometer], 29 degrees Celsius (�C) [85 degrees Fahrenheit (�F) air intake temperature,

and 1.29 kPa (0.38 in. Hg) water vapor pressure with No. 2 diesel fuel.

3. Maximum performance curves are nominal within a +5% tolerance band.

FIGURE 1. Performance data.
